Description
Designed and manufactured by Tremec, the TR-3650 is a 5-speed manual transmission that was first introduced in the 2001 Ford Mustang GT & Cobra’s. They were installed halfway through 2001 replacing the T-45. FoMoCo needed a stronger gearbox that could withstand additional torque output, so they turned to Tremec for a redesign.
Today, HMS rebuilds & customizes the Tremec TR-3650 and offers various options given the customer’s specific needs. The TR-3650 uses a 3pc 1-2 advanced synchronizer design, and carbon-lined synchro rings for 3-4-5 & reverse which are standard in every build. HMS has enabled the popular Tremec 3650 to be a legitimate option in a world so often dominated by Tremec’s other products like its five-speed heavy-duty transmissions, TKO-500 and TKO-600, and its six-speed transmissions, such as the T56, TR6060 & Magnum units.
Considering the vehicle’s weight, power, traction/tire size, and even driving style. A modified TR-3650 can fit a lot of different combinations, and is an affordable alternative to other Tremec Transmission units.
Standard Features:
- HMS Modified 01-04 Tremec TR-3650 Transmission
- Perfect for Ford or GM Applications
- 3PC 1-2 Rings – Advanced Synchronizer Design
- Carbon-Lined Synchro Rings 3-4-5, & Reverse
- Horsepower Rating – 650HP or Less
- Input Shaft – 26 Spline
- Output Shaft – 31 Spline
- Choice Of .62 or .68OD
- Dry Weight – 120 lbs
- 1 Shifter Location
- Electronic Speedo Only
- HMS Exclusive Billet Adapter Plate – Bolts to Tremec TKO, GM Muncie, Saginaw, or Ford Toploader Bellhousings
- UPR Products Shifter Included
- HMS Exclusive Billet 3-4 Shift Fork
Gear Ratios: 1st Gear: 3.38, 2nd Gear: 2.0, 3rd Gear: 1.32, 4th Gear: 1.00, 5th Gear: 0.62 or 0.68OD OPTION
NOTE: This HMS TR-3650 bolts to any Tremec TKO, GM Muncie, Saginaw, or Ford Toploader style bellhousings (bellhousing not included). Perfect for LS swaps, and other combinations like small and big block Chevrolet & Ford engines. May require additional items, or tunnel clearance. No core charge or exchange. All TR-3650 transmissions require a $800.00 core charge or exchange unit WITHIN 60 DAYS. All TR-3650 units are custom built to order, and may require up to 14+ weeks turn around time. UPR Products Shifter Included. Shifter Handle & Knob not included. This HMS TR-3650 will include our exclusive billet 3-4 shift fork for added strength and durability.
Additional Cost Options:
- Billet 1-2 Shift Fork – $189
- Bronze Shift Fork Pads – $60
- .81OD 5th Gear Option – $475
- PRO 5.0 Shifter – $164.95
